Chipper 2X EMV L2 smart card, EMV L1 contactless, dual track mag
Chipper™ 2X
Three in one mPOS device for magstripe, EMV & NFC cards
Chipper™ 2X mPOS solutions redefine performance, reliability and convenience for businesses that require superior mPOS technology. Its portable design prioritizes mobility – take Chipper™ 2X wherever you go.
Chipper™ 2X supports all magstripe and EMV payment functions and offers extended battery life, perfect for merchants with high volume use, such as fast food, delivery, and line-busting in shops. It also adds NFC capability, to process contactless payment transactions.
Chipper™ 2X
Three in one mPOS device for magstripe, EMV & NFC cards
Chipper™ 2X mPOS solutions redefine performance, reliability and convenience for businesses that require superior mPOS technology. Its portable design prioritizes mobility – take Chipper™ 2X wherever you go.
Chipper™ 2X supports all magstripe and EMV payment functions and offers extended battery life, perfect for merchants with high volume use, such as fast food, delivery, and line-busting in shops. It also adds NFC capability, to process contactless payment transactions.
Dual Track Magstripe, EMV and NFC Card Reader
![](https://www.bbpos.com/wp-content/uploads/2017/04/C2X_swipe.png)
Widely Compatible
Chipper™ 2X Specifications
Functions
- EMV chip card reader (ISO7816 compliant class A, B, C card)
- Magnetic Stripe Card Reader Dual tracks (track 1 & 2)
- NFC card reader (EMV contactless, ISO 14443A/B)
- Over-the-air firmware update
- Over-the-air key update
Communication Interface
3.5mm audio jack, Micro USB
Button
Reset button
Detection
Unplug detection
Power & Battery
Lithium polymer rechargeable battery 650mAh, 3.7V
Charging
Via Micro USB, 3 hours for fully charged
Indicator
LED status indicator & NFC LED indicators
Light Indicator
Green light On: Battery fully charged
Green light Flashing: During transaction
Red light On: Battery charging
Red light Flashing: Operating at low battery
4 Blue LEDs:
– follow EMV contactless standard.
– In standard version, the lighting pattern will be from left to right.
– In NAB version, as the device will be upside down, so the lighting pattern can be kept remain unchanged
Key Management
DUKPT, MK/SK
Encryption Algorithm
TDES
Firmware Update
Supported by audio, Bluetooth and USB, store in serial flash
Swipe Speed
15cm – 100cm/sec
Battery Life
Above 800 EMV transactions, or above 5000 magnetic card swipe transactions, or above 1000 EMV contactless transactions for one fully charge
Support Operation Systems
- Android 2.1 or above
- iOS 6.0 or above
- Windows Phone 8 or above
- Microsoft Windows
Operating Temperature
0℃ – 45℃
Operating Humidity
Maximum 95%
Storage Temperature
-20℃ – 55℃
Storage Humidity
Maximum 95%
Certifications*
- EMV Contact L1 & L2
- EMV Contactless L1
- VISA payWave
- MasterCard PayPass
- AMEX ExpressPay
- Discover Contactless D-PAS
- VISA Ready
- MasterCard TQM
- MasterCard Mobile POS
- Discover Network ZIP
- PBOC 3.0 L1 & L2
- QPBOC 3.0 L1 & L2
- FCC, CE, RoHS
Reliability
ESD 4k / 8k
Dimensions & Weight
![](https://www.bbpos.com/wp-content/uploads/2017/04/C2X_dimension_grey.png)
Products Model | Chipper 2X EMV L2 smart card, EMV L1 contactless, dual track mag |
---|---|
Barcode scanner | 1D scanner |
Manufacturer | BBPOS |
