Riotec iDC9277L GODASCAN 2D Bluetooth Barcode Scanner

Riotec iDC9277L GODASCAN 2D Bluetooth Barcode Scanner

The Riotec iDC9277L GODASCAN 2D Bluetooth barcode scanner is a unique Bluetooth scanner for iOS and Android phones, that will enable any iOS and Android PDA and mobilepostech to become a barcode scanner.

Product Description

With the Internet of Things (IOT), Android/iOS mobilepostech becomes the tool for data collection. RIOTEC develops the "GODASCAN”
which applied for Android/iOS mobilepostech use.

* DC9277L: Plug and Play (Wired, for Android OTG phone)
  iDC9277L: BT communication (wireless, for iOS device)
* With appropriate APP, the Android mobilepostech becomes data collector.
* With touch trigger, the operation is easy.
* GODASCAN can be used for different size of iOS / Android devices (from 4” to 6” size)
* The back of GODASCAN has PU glue / sucker which can be stuck on smart-phone strongly. PU glue can be repeatedly used.
* GODASCAN has Li-Ion battery inside which provides power to scanner.
* You don’t remove GODASCAN when in charge. You can charge both GODASCAN & mobilepostech through its micro USB port directly.

Specifications:

Model Name		iDC9277L	DC9277L
Description		BT GODASCAN	Wired GODASCAN
Engine		RIOTEC 2D engine
Performance Characteristics
Light source		625±10 nm LED
Depth of field		(20 mil Code 39)：320 mm
Sensor		CMOS (752×480 pixels)
Best resolution		1D (CODE39)≥ 5mil 2D (PDF417) ≥ 6mil
Reading angle		Tilt: 360° / Pitch ±50° / Skew ±50°
Print contrast		≥ 30%
Indicators		Beeper
charge		Micro USB port
Symbologies		Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ISBN/ISSN, Code 93, UCC/EAN-128, GS1 Databar, PDF417, QR Code, Data Matrix
Interface		through BT	USB OTG
Electrical Characteristics
Input voltage		5 V/DC ± 5%
Current - operating		230 mA
Radio Range		BT Class 1	-
RF Frequency		2.4GHz	-
Communication		HID profile, SPP profile	-
Battery Type		3.7V 900mAh Li-Ion battery
Scans per charge		more than 10,000 scans when fully charged
Charge Time		4 ~ 5 hours
Current Charging		500 mA
Power cable		Micro USB cable
Physical Characteristics
Dimension		125 X 52.5 X 35 mm (L * W * H)
Weight		88 g +/- 4 g
User Environment
Temperature-operation		'0°C to 50°C
Temperature-storage		-10°C to 60°C
Humidity-operation		95% relative humidity, non-condensing
Decode Zone
5 mil Code 39		60mm ~ 120mm
13 mil UPC-A		45mm ~ 260mm
20 mil Code 39		70mm ~ 320mm
6.67 mil PDF417		70mm ~ 125mm
10 mil DataMatrix		40mm ~ 160mm
20 mil QR Code		40mm ~ 275mm
