Invengo XC-AF11 High Performance Antenna
Invengo XC-AF11 High Performance Antenna
Invengo XC-AF11 green UHF antenna adopts a unique design, with high gain, high stiffness, excellent impact and vibration resistance. XC-AF11 circularly polarized antenna is the best choice for logistics, warehousing and asset tracking applications.
Main Features of XC-AF11 High Performance Green UHF Antenna
-
Operating Frequency
840 ~ 868 MHz and 902 ~ 928 MHz
-
High Gain
-
Linear Polarization
-
Low VSWR
-
Protection Level: IP65
-
Durable and clean design
-
Simple installation and maintenance
Specifications of XC-AF11 High Performance Green UHF Antenna
| Performance Parameter | Operating Frequency |
840 ~ 868 MHz 902 ~ 928 MHz |
| VSWR | ≤ 1.4:1 | |
| Gain | 7.15 dBi | |
| H-PlaneE-PlanePolarizationHPBWHPBW | 60˚70˚Linear | |
| Antenna Impedance | 50 Ω | |
| Environmental | Operating Temperature | -40˚C to 70˚C (-40˚F to 158˚F) |
| Storage Temperature | -40˚C to 70˚C (-40˚F to 158˚F) | |
| Humidity Range | 5% ~ 95% RH | |
| Protection Level | IP65 | |
| PhysicalDimensionsParameters |
291 x 291 x 52 mm 11.5 x 11.5 x 2 in |
|
| WeightCase Material | Approx.Plastic ASA,0,91Aluminiumkg / 2.0 Lbs | |
| Models | ID |
XC-AF11-FCC (902~928MHz) XC-AF11-ETSI (840~868MHz) |
